Inline Hydraulic Pressure Relief Valve – 40 L/min – 20–210 Bar – BSPP
Description
Description
Product Description
The VMDR40 Inline Hydraulic Pressure Relief Valve is designed to provide adjustable pressure relief in hydraulic circuits, helping protect hydraulic components against excessive system pressure.
Manufactured in Italy with a durable steel body, this compact inline valve features an adjustable relief pressure range of 20–210 bar and a maximum flow capacity of 40 litres per minute.
Available with 3/8" or 1/2" BSPP threaded ports, the VMDR40 series is suitable for hydraulic applications requiring an inline pressure relief solution.
Features & Benefits
-
Adjustable Pressure Relief: Set the relief pressure within the 20–210 bar adjustment range.
-
40 L/min Maximum Flow: Suitable for hydraulic circuits operating within the valve's rated flow capacity.
-
Steel Construction: Robust construction for hydraulic applications.
-
BSPP Threaded Connections: Available in 3/8" and 1/2" BSPP port sizes.
-
Compact Inline Design: Allows installation directly into suitable hydraulic plumbing arrangements.
-
Italian Manufactured: VMDR series hydraulic valve manufactured in Italy.
Technical Specifications
| Specification | Details |
|---|---|
| Valve Type | Inline Hydraulic Pressure Relief Valve |
| Series | VMDR40 |
| Maximum Flow | 40 L/min |
| Adjustable Pressure Range | 20–210 Bar |
| Maximum Rated Pressure | 350 Bar |
| Port Sizes | 3/8" BSPP or 1/2" BSPP |
| Body Material | Steel |
| Country of Manufacture | Italy |
Available Sizes
3/8" BSPP
-
Manufacturer Part Number: VMDR40-3802C
-
Tas Hose SKU: 04-HV-RV-VMDR40-3802C
1/2" BSPP
-
Manufacturer Part Number: VMDR40-1202C
-
Tas Hose SKU: 04-HV-RV-VMDR40-1202C
Important Information
Relief pressure must be correctly adjusted and verified for the intended hydraulic application. Ensure the valve's flow capacity, pressure range and port configuration are suitable for the hydraulic circuit.
The 20–210 bar figure refers to the adjustable relief setting range, while 350 bar is the manufacturer's maximum pressure rating. These are different specifications.
